ABB PDB-02 3HNA023093-001: Thermocouple/mV Input Module

Thermocouple Compatibility:Wide range of thermocouple types supported

Input Range:-200°C to +1800°C

Signal Conversion:Direct conversion of thermocouple output to mV signal

Accuracy:±0.5% of full scale

Power Consumption:Less than 2.5mA at 24V DC

Environmental Conditions:Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C

Mechanical Specifications:IP65 rated, rugged design for harsh environments

    The ABB PDB-02 Thermocouple/mV Input Module, model 3HNA023093-001, stands out for its precision and robustness in industrial environments. Designed to integrate seamlessly with any PLC system, this module ensures accurate temperature and voltage measurements essential for process control and monitoring.

    With compatibility for a wide range of thermocouple types, users can easily adapt to different industrial applications without compromising on performance. The module supports both 0-10V and 4-20mA input ranges, providing flexibility in signal acquisition.

    Offering a resolution of 0.01°C or 0.01mV, the ABB PDB-02 ensures high-level accuracy, crucial for applications requiring meticulous attention to detail. Its fast sampling rate of 10 samples per second enables real-time monitoring and adjustment, enhancing operational efficiency.

    In terms of power consumption, the module is designed to be energy-efficient, drawing up to 15mA, which minimizes load on the system and reduces operational costs. Withstanding harsh environmental conditions from -20°C to +55°C for operation and -40°C to +70°C for storage, it ensures reliable performance in various industrial settings.

    The standard 2-wire connection simplifies installation and maintenance, making the ABB PDB-02 an ideal choice for retrofitting or new installations. Its modular design allows for easy integration into existing automation systems, streamlining setup and deployment.
