General Electric SR469-P5-HI-A20-H - Advanced Motor Management Relay

General Electric SR469-P5-HI-A20-H – Advanced Motor Management Relay

In stock

The General Electric SR469-P5-HI-A20-H is a high-performance Motor Management Relay designed for industrial applications. It offers advanced protection features including torque protection, undervoltage and overvoltage protection, and current unbalance correction, ensuring prolonged motor life and reduced downtime.

Manufacturer:General Electric Company USA, GE Industrial Systems

Voltage Supply:AC: 70 to 265 V @ 48-62 Hz

Phase Current:5A

Phase Protocol:Modbus RTU/ Half Duplex

Analog Outputs:4-20 mA Burden > 500 kΩ

Stall Ratio:Hot and Cold Safe

Control Power Range:90 to 300 VDC or 70 to 265 VAC at 48-62 Hz

Optional Features:Ethernet 10BaseT, RJ45 connection, Conformal Coating

RTD Inputs:Multiple RTD inputs for temperature monitoring (100 ohm Nickel, 120 ohm Nickel, 10 ohm Copper, 100 ohm Platinum)

LCD Display:Larger LCD for enhanced visibility

The GE SR469-P5-HI-A20-H is a versatile motor management relay designed for industrial environments.

It features advanced protective elements such as torque protection, mechanical jam, undervoltage, overvoltage, and current unbalance correction.

These features are highly configurable and can be set based on user-defined parameters and time intervals.

This model includes the optional Ethernet 10BaseT, RJ45 connection, which allows for seamless integration with existing industrial networks.

Additionally, the SR469-P5-HI-A20-H supports multiple RTD inputs for accurate temperature monitoring of the motor system, ensuring optimal performance and longevity.

The conformal coating enhances the relay’s resistance to harsh environmental conditions, making it suitable for use in challenging industrial settings.

GE SR469-P5-HI-A20-H
