Mitsubishi 2098-DSD-HV100-SE Servo Drive

Input Voltage (AC):230 to 480 Vrms, 3-Phase

Input Frequency (AC):47 to 63 Hz

Nominal Input Current (AC):7 A

Continuous Output Current:11 A (0-peak)

Intermittent Output Current:22 A (0-peak)

Size:9.54 x 14.2 x 5.46 inches (242.2 x 360.7 x 138.7 mm)

Supporting Interfaces:RS232, RS485, DeviceNet

Supported Encoders:Multi-turn absolute encoders

    Integrally designed for superior performance and reliability, the Allen-Bradley 2098-DSD-HV100-SE Servo Drive offers seamless integration with Allen-Bradley’s ControlLogix platform, enhancing operational efficiency in a variety of industrial settings.

    Equipped with advanced indexing capabilities, this drive ensures precise motor control, making it an ideal choice for applications requiring high accuracy and dynamic response.

    The drive supports multi-turn absolute encoders, facilitating accurate feedback for enhanced control and positioning accuracy. This feature also allows for the provision of external logic power, contributing to energy efficiency and reduced maintenance requirements.

    Featuring a robust and compact design, the Allen-Bradley 2098-DSD-HV100-SE Servo Drive delivers exceptional power density, making it suitable for space-constrained environments without compromising on performance.

    Designed with user convenience in mind, the drive includes an integrated RS232/RS485 interface, simplifying communication with various control systems. Additionally, the inclusion of an AC line filter ensures compatibility with diverse electrical systems, promoting universal application across various industrial sectors.
