Tektronix 5B12N High-Performance Arbitrary Function Generator

In stock

The Tektronix 5B12N Arbitrary Function Generator offers high-precision waveform generation capabilities, ideal for testing and calibration in various industrial control systems and electronic applications.

Frequency Range:1 MHz – 1 GHz

Output Power:+10 dBm to -120 dBm

Phase Noise:-130 dBc/Hz at 10 kHz offset

Frequency Stability:±1 ppm

Harmonic Distortion:-70 dBc

Interface:Ethernet, USB, GPIB

Resolution:0.01 Hz

The Tektronix 5B12N Signal Generator is designed to deliver high-quality signal generation with exceptional accuracy and reliability. With its wide frequency range from 9 kHz to 1 GHz, it caters to a variety of test and measurement needs. The device ensures precise amplitude and phase control, making it ideal for complex signal generation tasks. Its low phase noise and harmonic distortion levels provide clean and stable signals for accurate testing. The Tektronix 5B12N supports multiple modulation types including AM, FM, PM, FSK, ASK, and PWM, enabling versatile applications. The output impedance of 50 Ohms ensures compatibility with a wide range of devices and systems. Additionally, the device is equipped with interfaces like GPIB, USB, and LAN for easy integration into modern test setups.

TEKTRONIX 5B12N
