Tektronix 5B40 Arbitrary Function Generator, High Precision Waveform Generation

In stock

The Tektronix 5B40 Arbitrary Function Generator (AFG) is a versatile signal generator designed for a wide range of applications in electronics testing and development. It offers precise control over waveform generation and can simulate various signals for accurate testing and calibration.

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary

Frequency Range:0.1 μHz to 50 MHz

Amplitude Range:20 mVpp to 10 Vpp into 50 Ω

Resolution:14-bit vertical resolution

Output Impedance:50 Ω

Phase Shift:0 to 360 degrees

Built-in Arb Memory:2 GSa/s sampling rate, 16 kpts memory depth

The Tektronix 5B40 Arbitrary Function Generator (AFG) is a high-performance tool designed to meet the needs of modern electronic engineering and research laboratories. With its extensive waveform generation capabilities, it supports sine, square, triangle, ramp, pulse, noise, and arbitrary waveforms. The frequency range from 0.1 μHz to 20 MHz makes it suitable for a wide variety of applications, including telecommunications, audio testing, and medical device testing. The amplitude resolution of 1 μVpp to 10 Vpp ensures precise signal control, while the 14-bit resolution provides excellent accuracy and repeatability. The 3.5-inch TFT color display allows users to easily view and adjust settings, making it user-friendly and intuitive. Connectivity options include USB, Ethernet, and GPIB, facilitating integration with other laboratory equipment and systems. Designed with reliability and ease of use in mind, the Tektronix 5B40 AFG is an indispensable asset for any professional electronics lab.

TEKTRONIX 5B40
