AB 1756-CN2/C Capacity ControlNet Bridge Module

Model Type:Communication Bridge Module

Manufacturer:Allen-Bradley

Model Number:1756-CN2/C

Power Supply:5.1 W

Communication Protocol:Ethernet/IP

Mounting:Chassis

Temperature Rating:0 – 60 DEG C

Connection Cables:802.3 Compliant Shielded Or Unshielded Twisted Pair

Environmental Conditions:5 – 95% Non-Condensing Relative Humidity

Vibration Resistance:2 G

Shock Resistance:30 G

Interface:Ethernet

    Experience seamless integration with the AB 1756-CN2/C Capacity Bridge Module, an essential component for enhancing communication efficiency in your industrial automation setup. Designed for compatibility with ControlLogix systems, this module ensures robust, reliable data transmission.

    Featuring a compact chassis mounting design, the module is built to withstand demanding industrial environments. Its high-speed Ethernet/IP interface facilitates fast data transfer rates, crucial for real-time operations and responsive control systems.

    Equipped with advanced isolation technology, the 1756-CN2/C provides a continuous 30 V isolation barrier, ensuring protection against electrical disturbances and enhancing system reliability. This feature is particularly beneficial in environments prone to voltage fluctuations or electromagnetic interference.

    With its wide operating temperature range of 0 to 60 degrees Celsius, the module is suitable for use in various climate conditions, making it a versatile choice for global applications. Additionally, the module’s robust construction withstands vibrations and shocks, ensuring stable operation even under extreme conditions.

    For optimal performance, connect the 1756-CN2/C with 802.3 compliant shielded or unshielded twisted pair cables, ensuring secure and efficient data communication. The included documentation guides you through installation and configuration, simplifying the integration process and ensuring seamless operation within your existing automation infrastructure.
