3BHE004385R0001 – ABB Sensor

Brand:ABB

Model:3BHE004385R0001

Sub-Model:UNSO884a,V1

Category:Current Sensor

Type:Hall Effect

Measurement Range:0 to 1000 A

Accuracy:±0.5% F.S.

Operating Temperature:-40°C to +85°C

Supply Voltage:DC 5 to 30 V

Response Time:≤ 10 ms

Dimensions:40 mm x 16 mm x 12 mm

Connectors:2-pin M12

Protection Rating:IP67

Material:Stainless Steel Housing

    The ABB 3BHE004385R0001 UNS0884a, V1 Current Sensor features a compact and durable design that makes it suitable for integration into various industrial applications. It employs advanced Hall Effect technology for highly accurate current measurements, ensuring precise control and monitoring of electrical circuits.

    This sensor is equipped with a wide operating temperature range, making it ideal for use in extreme conditions encountered in manufacturing and process industries. Its accuracy is rated at +/- 1% of full scale, providing reliable data for critical control processes.

    With an operating voltage from 12V DC to 24V DC, the sensor is compatible with a broad spectrum of power supplies found in industrial settings. It can measure currents up to 10A, making it suitable for monitoring both low and high current flows.

    The output signal of 4 to 20mA ensures compatibility with common industrial control systems and devices, allowing seamless integration into existing automation networks. The sensor’s quick response time facilitates real-time monitoring and control, enhancing operational efficiency.

    Additionally, the IP67 protection class indicates its ability to withstand dust and water ingress, ensuring reliable performance even in challenging environments. This makes the ABB 3BHE004385R0001 UNS0884a, V1 Current Sensor a valuable asset for maintaining safety and efficiency in industrial automation.
