ABB 3HAA3563-APA Backplane Control Board

Operating Voltage:24 VDC

Input Current:0.2 A

Output Current:2.5 A

Communication Protocol:CANopen

Temperature Range:-25°C to +60°C

Board Size:100 x 100 mm

Connection Type:Pin Header

Memory Capacity:16 KB

    Engineered with cutting-edge technology, the ABB 3HAA3563-APA Backplane Control Board offers unparalleled performance in industrial settings. Its robust design ensures compatibility with a wide range of control systems, making it a versatile choice for various manufacturing sectors.

    Featuring an extensive array of input/output channels, this control board enables precise monitoring and control of industrial processes. Whether it’s managing machinery operations or overseeing production lines, the ABB 3HAA3563-APA ensures smooth and efficient workflow.

    With its wide operating temperature range (-25°C to +70°C), this control board can withstand harsh industrial environments, ensuring reliable operation in even the most demanding conditions. The low power consumption (max. 15W) contributes to energy efficiency and cost savings.

    The inclusion of multiple communication interfaces, such as RS-485, Modbus TCP/IP, Ethernet, CANbus, and serial communication, facilitates seamless integration with existing infrastructure and enhances the board’s adaptability to diverse system requirements.

    Built to meet global safety and compliance standards, the ABB 3HAA3563-APA Backplane Control Board is UL, CE, and CSA certified. This not only ensures reliability but also simplifies the procurement process for international projects.
