Allen Bradley 1746-NIO4V SLC 500 Analog Input & Output Module

Model Type:Analog Combination Module

Number of Channels:2 (Input), 2 (Output)

Input Type:High Resolution

Common Mode Voltage Range (Input):-20 To 20 V

Absolute Input Voltage (Input):Plus/Minus 7.5 VDC Or 7.5 VAC RMS (Maximum)

Input Range (Current):-20 To 20 MA

Absolute Input Current (Maximum):-30 To 30 MA

Output Range (Voltage):-10 To 10 V – 1 LSB

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Input Range (Voltage):-10 To 10 VDC – 1 LSB

Current Rating:Backplane Current Draw: 55 MA

Isolation:Backplane: 500 VDC

Enclosure Type:Open Type

Display:Status LED

Connection Cables:24 – 14 AWG

Mounting:Chassis

    The Allen Bradley 1746-NIO4V SLC 500 Analog Module is designed for seamless integration into complex industrial control systems, ensuring reliable performance under a wide range of environmental conditions.

    Equipped with advanced signal processing capabilities, this module provides exceptional precision and accuracy, making it suitable for applications that demand meticulous control over operational parameters.

    Built to withstand the rigors of industrial use, this module boasts robust isolation and overvoltage protection, safeguarding against potential electrical hazards and ensuring system reliability.

    Offering versatile connection options, the 1746-NIO4V is compatible with various communication protocols, facilitating seamless data exchange within industrial networks.

    With its compact design and efficient power consumption, this module optimizes space utilization and reduces overall energy costs, contributing to a more sustainable and cost-effective operation.
