Allen Bradley 1786-TPYR Thermocouple Input Module

Module Type:Temperature Process Module

Compatibility:Allen Bradley ControlLogix

Input Range:0-1000°C

Resolution:0.1°C

Accuracy:±0.5% of reading ±1°C

Communication Interface:Ethernet/IP, Modbus TCP

Operating Temperature:-40°C to 85°C

Power Supply:24V DC

    Designed for industrial automation systems, the Allen Bradley 1786-TPYR Thermocouple Input Module delivers high accuracy and reliability for temperature measurement. Its robust construction ensures long-term durability even in harsh environments.

    With 8 thermocouple input channels, this module supports various types of thermocouples, including K, J, T, R, S, B, N, and E. This versatility makes it suitable for a wide range of industrial applications.

    The 1786-TPYR features a high-resolution 14-bit ADC for precise temperature readings. The accuracy of ±0.5°C or ±0.2% of reading ensures that your process remains within tight tolerance limits.

    Fast response time of less than 10 milliseconds allows for real-time monitoring and quick adjustments to changing conditions. The module communicates via Modbus RTU over RS485, ensuring seamless integration with existing industrial networks.

    The Allen Bradley 1786-TPYR is built to withstand operating temperatures from -40°C to 85°C, making it ideal for use in extreme environments. Its compact design allows for easy installation in crowded control panels, saving valuable space.
