AMCI 1241: 1-Channel Resolver Unit – Precision Motion Control Solutions

Model:AMCI 1241

Type:Single-Channel Resolver

Operating Temperature Range:-40°C to +85°C

Resolution:±0.01°

Input Voltage:12V DC ±5%

Output Voltage:1.5V DC ±0.2V at full scale

Operating Frequency:Up to 10 kHz

Rotational Speed:Up to 1000 RPM

Enclosure Rating:IP65

Weight:Approx. 0.15 kg

    The AMCI 1241 Resolver Unit is engineered with precision in mind, providing exceptional performance in industrial automation tasks. Its compact size and lightweight aluminum housing make it highly portable and durable, ensuring reliable operation in harsh environments.

    Equipped with a 12-bit resolution, this resolver unit ensures accurate measurement and control of mechanical movements, crucial for applications requiring high precision, such as robotics, CNC machines, and precision machinery.

    Operating within a temperature range from -40°C to +85°C, the AMCI 1241 Resolver Unit is designed to withstand extreme conditions, making it ideal for use in diverse industrial settings. It is compatible with a wide range of power supplies between 10V to 30V, providing flexibility in various installation scenarios.

    With a low current consumption of up to 50mA, this resolver unit is energy-efficient, reducing operational costs without compromising on performance. Its BNC connector facilitates easy integration into existing systems, ensuring seamless installation and operation.

    Featuring an IP65 enclosure rating, the AMCI 1241 Resolver Unit is protected against dust and water ingress, guaranteeing reliable performance even in dusty or wet environments. This robust design ensures longevity and maintenance-free operation, minimizing downtime and maximizing productivity.
