BK5220 – Industrial Module

Extended Product Type:Other

Product ID:BK5220

Beckhoff Type Designation:Other

Number of I/O Stations:64

Operating Modes:Bit Strobe, Polling, Cyclic, Change of State (COS)

Number of Bus Terminals:64

Max. Number of Bytes Fieldbus:512 input, 512 output

Digital Peripheral Signals:1,020 inputs/outputs

Power Supply:24 V DC (-15 %/+20 %), through bus cable | 11…25 V (DeviceNet specification)

Input Current:70 mA + (total K-bus current)/4, 500 mA max.

Current Supply K-bus:1750 mA

Weight:Approx. 130 g

    The Beckhoff BK5220 DeviceNet Bus Coupler is engineered for high-performance industrial environments, ensuring reliable data transfer and control across multiple devices.

    With its robust design and extensive compatibility, this coupler enables seamless integration within complex automation networks, facilitating efficient operation and maintenance.

    Equipped with a versatile array of input/output terminals, it supports a wide range of digital peripheral signals, enhancing system flexibility and adaptability.

    Featuring advanced operating modes such as Bit Strobe, Polling, Cyclic, and Change of State (COS), the BK5220 ensures smooth data flow and precise control in real-time applications.

    Operated on a reliable 24V DC power supply and compatible with various voltage levels, it ensures stable performance under diverse environmental conditions, making it a trusted choice for industrial automation.
