B&R X20CP1483 CPU Module – High-Performance Control Core

Processor Type:Intel x86-based, 100 MHz-compatible

Integrated I/O Processor:Yes

Onboard Ethernet:Yes

POWERLINK Interface:Yes

USB Ports:2

CompactFlash Memory:Removable

Fanless Design:Yes

Interfaces:1x RS232, 1x Ethernet, 1x POWERLINK (V1/V2)

System Module:CPU

Status Indicators:CPU function, overtemperature, Ethernet, POWERLINK, CompactFlash, battery

Power Consumption:Internal I/O: 0.6 W

Input Voltage:24 VDC -15% / +20%

Input Current:Max. 2.2 A

Processor Speed:100 MHz compatible

RAM:32 MB SDRAM

    Engineered with efficiency at its core, the B&R X20CP1483 CPU Module is a powerful addition to any industrial control system. Its compact design seamlessly integrates with existing infrastructures, ensuring minimal space consumption without compromising on performance.

    Equipped with an Intel x86-based processor, this module ensures compatibility with 100 MHz systems, delivering unparalleled speed and reliability. The integrated I/O processor enhances its versatility, making it suitable for a wide range of automation tasks.

    With onboard Ethernet, POWERLINK, and USB connections, the X20CP1483 offers seamless connectivity options, facilitating communication across various devices and systems. Its inclusion of an X2X Link further amplifies its networking capabilities.

    Featuring CompactFlash as a removable application memory, the module ensures easy storage and retrieval of data, providing flexibility in software updates and maintenance. The fanless design ensures quiet operation, contributing to a more efficient work environment.

    The B&R X20CP1483 comes equipped with essential status indicators, including CPU function, overtemperature, Ethernet, POWERLINK, CompactFlash, and battery status, enabling users to monitor the health and performance of their system in real-time. This comprehensive monitoring capability ensures proactive maintenance and minimizes downtime.
