EMERSON 12P4627X072 VDC High Side Module

Power Supply Voltage:48 VDC

Operating Frequency:12 kHz

Current Capacity:150 A

Switching Technology:MOSFET

Temperature Range:-40°C to +125°C

Input Logic Voltage:5 V

Control Interface:Digital

Efficiency Rating:98%

Protection Features:Overcurrent, Overvoltage, Short Circuit

    The EMERSON 12P4627X072 VDC High Side Module is a high-performance switch tailored for industrial control systems. It ensures stable and precise switching operations, crucial for maintaining system reliability and efficiency.

    With a wide operating voltage range of 400V DC and a switching frequency of 50 kHz, this module is versatile and adaptable to various industrial applications. It supports a maximum switching capacity of 10A, making it suitable for a broad spectrum of high-power switching tasks.

    Constructed with a N-channel MOSFET, the module offers low on-resistance, which reduces power loss and improves overall system performance. Its compact 5x5mm SOT-23-5 package size facilitates easy integration into space-constrained designs, enhancing the flexibility of system layout.

    Designed for extreme environmental conditions, the module operates within a temperature range of -40°C to +125°C, ensuring reliable performance in harsh industrial environments. This robust design is complemented by compliance with international standards, including ISO9001 for quality management, UL for safety, CE for conformity to European economic areas, and RoHS for environmental friendliness.

    Ideal for applications requiring high-side switching, such as motor control, power supply management, and safety circuits, the EMERSON 12P4627X072 VDC High Side Module is an indispensable component for engineers aiming to build efficient and dependable industrial control systems.
