Rated Voltage (V):600
Current Rating (A):200
Switching Frequency (kHz):10
Operating Temperature Range (-°C to +°C):-40°C to +170°C
Insulation Resistance (Ω):≥ 10^12
Operating Ambient Temperature Range (-°C to +°C):-10°C to +50°C
Storage Temperature Range (-°C to +°C):-60°C to +150°C
Mechanical Connection:M12 connectors
Dimensions (mm):120 x 70 x 40
The EUPEC BSM200GB170DLC IGBT Module is a cutting-edge solution for demanding industrial control environments, featuring a robust design optimized for exceptional performance and durability. It excels in motor control applications, delivering precise power switching with minimal loss and high efficiency.
This IGBT Module is equipped with advanced thermal management systems, including a thermal pad and heat sink, ensuring stable operation even under extreme conditions. Its wide operating temperature range (-40°C to +170°C) allows for deployment in various industrial settings, from freezing cold climates to hot manufacturing floors.
With a continuous current capacity of 200A and a switching frequency of 100kHz, this module is capable of handling complex and high-power tasks efficiently. The high insulation resistance (≥100MΩ) ensures reliable isolation and protection against electrical hazards.
The EUPEC BSM200GB170DLC supports PWM (Pulse Width Modulation) or gate drive input signals, offering flexibility in integration with different control systems. It’s designed for seamless integration into existing industrial automation setups, enhancing system capabilities without requiring extensive modifications.
This module is an excellent choice for manufacturers looking to improve energy efficiency, reduce downtime, and increase overall system performance in their operations. With its superior reliability and robust construction, it stands as a testament to EUPEC’s commitment to delivering top-tier products for the industrial sector.
