GE 489-P5-LO-A20-E-H Generator Management Relay – Industrial Control

Analog Current Outputs:Isolated with RTDs and analog inputs up to 36 Vpk

Case Drawout:Fully drawout (automatic CT shorts)

Digital Inputs:Configurable and assignable to Digital Inputs 1 to 7

Sensor Supply:24 V DC at 20 mA max

Impedance:N/A

Time Delay:0.1 to 100.0 s in steps of 0.1

Negative Sequence Overcurrent Pickup Level:3 to 100% FLA in steps of 1

Sequential Trip:Configurable and assignable to Digital Inputs 1 to 7

Shipping Weight:7.7 kg or 17 lbs.

    The GE 489-P5-LO-A20-E-H is an advanced generator management relay engineered for robust performance in demanding industrial environments.

     Its key features include low voltage 4-20 mA analog output, which provides precise control over generator operations.

     The relay supports up to five ampere CT secondary phase current inputs, making it highly versatile for various applications.

     Equipped with programmable phase overcurrent voltage restraint, it ensures reliable operation under different conditions.

     The tachometer function allows for configurable assignment to digital inputs, enhancing system integration flexibility.

     With its lightweight design and durable construction, this relay is ideal for critical applications where precision and reliability are paramount.
