DS3800NSFC1G1E – GE Board

In stock

This advanced printed circuit board is designed for use in General Electric’s Mark IV turbine control systems, offering robust performance and safety mechanisms for steam and gas turbines. It integrates essential components and circuitry, providing reliable automation and protection capabilities.

Manufacturer:General Electric

Model Number:DS3800NSFC1G1E

Board Type:System Firing Board

Integrated Circuits:28, including hex inverters, oscillators, and octal D-type transparent latches

Dimensions:12 inches x 6 inches

Weight:2 lbs

Compatibility:For use with GE‘s Mark IV Speedtronic Series

Features:Automatic start-up and cool-down routines, enhanced safety features, optional auxiliary board support

The DS3800NSFC1G1E is a state-of-the-art printed circuit board engineered specifically for industrial turbine control applications within the Mark IV Speedtronic system.

This board is equipped with a diverse array of twenty-eight integrated circuits that include hex inverters, oscillators, and octal d-type transparent latches, enhancing its performance and reliability.

Designed with redundancy in mind, it offers multiple backup options for critical controls and parameters, ensuring continuous operation even under adverse conditions.

The inclusion of an optional auxiliary board allows for additional potentiometers, providing greater flexibility and control over system parameters.

This advanced board supports automated startup and cooldown procedures, streamlining operational efficiency and reducing manual intervention.

Furthermore, it incorporates sophisticated safety mechanisms to prevent system operation under potentially hazardous conditions, safeguarding equipment and personnel.
