GE IS200TREGH1BDC: Advanced Termination Board for Mark VI Systems

Brand:General Electric

Model:IS200TREGH1BDC

Series:Mark VI

Category:Termination Board

Dimensions:170mm x 110mm x 30mm

Weight:0.5kg

Input Voltage:9-36V DC

Output Current:1A

Operating Temperature Range:-40°C to +85°C

Storage Temperature Range:-40°C to +85°C

Environment Compatibility:IP20, dustproof

Material:Aluminum alloy and plastic housing

Connector Types:DIN41612 connectors

Number of Connectors:Multiple

Mounting Method:Panel mounting

Certifications:CE, UL, FCC

    The GE IS200TREGH1BDC Termination Board is meticulously designed for seamless integration into GE‘s Mark VI turbine control systems, ensuring optimal electrical termination for enhanced system reliability.

    Equipped with three variable resistors for adjustable resistance values, this board allows for fine-tuning of system parameters to meet specific operational needs.

    Sitting along the right border, three Jack connector ports facilitate secure connections to various system components, promoting efficient data transfer and power distribution.

    Four rectangular capacitors, arranged in pairs at strategic locations, provide stable energy storage, crucial for maintaining system performance under varying conditions.

    Crafted from high-grade insulating material, the board ensures electrical safety and durability in harsh industrial environments, offering a reliable solution for extended operation periods.

    With an operating temperature range from -40°C to +85°C and a specified 24V DC operating voltage, this board is engineered to withstand extreme conditions, ensuring continuous system functionality in diverse applications.
