GE SR745-W3-P5-G5-HI – Transformer Management Relay with Enhanced Display and Control

Weight:4.8kg

Voltage Input:Burden less than 0.025 VA at 120 V

Source VT:2 to 600 kV / 60 to 120 V

Number of Logic Inputs:16

Manufacturer:General Electric

Fuse Current Rating:3.15 A

Features:Enhanced Display, High Control Power

Software Version:EnerVista 745 Setup

Operating Temperature Range:-40°C to +60°C

Chassis Series:745 SR Series

Input Voltage:60 to 120V

Display Resolution:40 Character LCD

IRIG-B Input Impedance:70 to 100 kΩ

    The GE SR745-W3-P5-G5-HI is meticulously designed to provide reliable monitoring and protection for transformers of various sizes. Its enhanced 40-character LCD display ensures clear visibility of operational status and error alerts, facilitating quick decision-making.

    This transformer management relay is capable of functioning independently or in conjunction with other relays in the GE Multilin 745 series. It features a robust keypad for manual entry of setpoints, simplifying the configuration process and enhancing user experience.

    The device supports a wide range of input voltages and logic inputs, making it adaptable to diverse industrial environments. With its advanced control power capabilities, it efficiently manages transformer operations while minimizing energy loss.

    The compact design with dimensions of 9 inches in height, 7 inches in width, and 7 ⅛ inches in depth ensures seamless integration into existing control systems. The case’s sturdy construction guarantees durability and reliability over extended periods of use.

    Equipped with a comprehensive set of LEDs, the GE SR745-W3-P5-G5-HI provides real-time status updates and error notifications directly on the front panel. This feature enhances operational safety and allows for prompt troubleshooting.
