JL PCL-813 – Isolated Analog Input Card: JL Electronics, Model 813, Analog Input Module

Model:PCL-813

Type:Isolated Analog Input Card

Brand:JL

Analog Input Channels:16

Operating Voltage:DC 5V – 24V

Signal Range:-10V to +10V or 0V to +10V

Resolution:12-bit ADC

Sampling Rate:1000 samples/sec

Isolation Voltage:2000V AC

Operating Temperature:-40°C to +85°C

Storage Temperature:-40°C to +85°C

Dimensions:100mm x 50mm

Weight:100g

Communication Interface:RS-485

    The JL PCL-813 Isolated Analog Input Card is engineered for critical applications requiring high-precision data acquisition, boasting an isolation rating of 1000VAC that ensures robust protection against electrical interference.

    Featuring eight independent analog input channels, this module offers flexibility in monitoring various physical parameters such as temperature, pressure, and flow rates across diverse industrial settings.

    With a versatile supply voltage range of DC 5V to DC 30V, the JL PCL-813 can operate seamlessly in a wide variety of environments, ensuring compatibility with existing power sources.

    Engineered for durability and reliability, this module is designed to withstand extreme temperatures from -40°C to +85°C, making it suitable for harsh industrial conditions.

    Equipped with a fast data acquisition speed of 100ms, the JL PCL-813 ensures real-time monitoring and response capabilities, enhancing operational efficiency and system performance.
