Koyo D3-DSCBL-2 Digital Input Module

Input Channels:16

Voltage Range:10-30V DC

Current Consumption:Typical 20mA per channel

Operating Temperature:-20°C to +70°C

Communication Interface:RS485

Power Supply:24V DC

    The Koyo D3-DSCBL-2 is an advanced digital signal conditioning module designed for industrial automation environments. It ensures reliable data acquisition and processing, providing accurate and stable signals for industrial control systems.

    This module is compatible with DirectLogic 205 series controllers, offering seamless integration into existing industrial systems. Its wide input range of ±10V, ±5V, 0-10V, and 0-5V, along with a 16-bit resolution, ensures high precision and reliability.

    With a sampling rate of up to 100 Hz, the D3-DSCBL-2 can handle fast-changing signals efficiently, making it suitable for real-time monitoring and control applications. The robust design includes built-in protection against overvoltage and short circuits, ensuring long-term stability and durability.

    The module supports multiple communication protocols including RS-232 and RS-485, enabling easy integration with various industrial devices and networks. Its 24V DC power supply ensures compatibility with a wide range of industrial power sources.

    Designed for ease of use, the Koyo D3-DSCBL-2 features a user-friendly interface and comprehensive documentation, simplifying setup and maintenance processes. Its compact size makes it ideal for space-constrained applications while still delivering superior performance.
