Mercury C-663 STEPPER Module

Manufacturer:Mercury

Model:C-663

Type:Stepper Motor

Voltage Range:24-110V DC

Rated Current:3.0 A

Step Angle:1.8°

Torque Rating:20 Nm

Operating Temperature:-20°C to +80°C

Dimensions:120mm x 90mm x 80mm

Weight:3.5 kg

    The MERCURY STEP C-663 STEPPER is engineered to deliver exceptional precision and reliability in demanding industrial environments. Its robust construction ensures long-term durability, while its advanced design minimizes vibration and noise during operation.

    This stepper motor is designed with a 2-phase configuration, offering a step angle of 1.8°, which enables fine control over positioning and movement. With a rated torque of 1.2Nm, it can handle substantial loads efficiently.

    The C-663 STEPPER operates within a wide temperature range from -20°C to +80°C, making it suitable for various environmental conditions. Its flange mount style provides secure and stable installation, ensuring consistent performance over time.

    Key features include a resistance of 0.5 Ohms and an inductance of 2 mH, contributing to efficient power consumption and smooth operation. The motor is compatible with a variety of controllers and drivers, providing flexibility in system integration.

    With its high precision and robust design, the MERCURY STEP C-663 STEPPER is an excellent choice for industrial automation projects requiring precise motion control. Whether you are building robotic systems, CNC machines, or other automated equipment, this stepper motor delivers the performance you need.
