NI NI-9505 Industrial Control Module

Manufacturer:National Instruments

Model:NI-9505

Module Type:Analog Input Module

Channels:8 Channels

Resolution:16-bit

Sampling Rate:1 MS/s

Input Range:+/-10V

Power Supply:5V DC

Operating Temperature:-40°C to +85°C

Dimensions:120mm x 90mm x 35mm

Weight:250g

    The NI NI-9505 Data Acquisition Module is meticulously designed for integration into industrial automation systems. It provides robust performance and reliability, ensuring seamless operation even in harsh environments.

    This module supports up to 32 channels, offering flexibility for various industrial applications. Its high sampling rate of 1 MS/s ensures fast and accurate data collection, critical for real-time monitoring and control.

    With a 16-bit resolution, the NI NI-9505 delivers precise measurements, making it suitable for demanding applications such as test and measurement, manufacturing processes, and environmental monitoring.

    Designed for durability, the module operates within a wide temperature range from -40°C to +85°C, ensuring reliable performance in extreme conditions. Its compact dimensions (165mm x 100mm x 25mm) make it easy to integrate into existing systems.

    The NI NI-9505 is powered by a 5V DC supply, simplifying installation and maintenance. Its lightweight design (0.3kg) makes it convenient for mounting and handling in various settings.
