Prosoft MVI56-MNET Ethernet Network Interface Module

Product Type:Network Interface Module

Product ID:MVI56-MNET

Extended Features:Supports up to 30 clients and 20 servers

Response Time:Faster response for multi-server applications

Communication Impact:Minimizes impact to other server communications when one server device goes offline

Server Capability:Provides access for Human Machine Interfaces (HMIs), Supervisory Control and Data Acquisition (SCADA), or Distributed Control Systems (DCS)

Integrated Software:RSLogix™ 5000 compatible using AOI or ladder file integration

No Additional Programming Required:No extra PAC/PLC programming needed

Configuration:Easy IP address configuration for simple setup

Backward Compatibility:Backwards compatible with previous versions

Ethernet Configuration:10/100 Mbps auto crossover detection

Application Port:User-definable module data memory mapping up to 5000, 16-bit registers

CIPconnect Support:CIPconnect-enabled network configuration and diagnostics monitoring

Reduced I/O Image Size:Optimized for remote rack implementations

Configuration Builder Software:ProSoft Configuration Builder (PCB) software for streamlined setup

    The Prosoft MVI56-MNET Network Interface Module is designed for seamless integration into industrial control systems, ensuring high-speed, reliable communication between your ControlLogix processor and external devices. This module supports up to 30 clients and 20 servers, making it an ideal choice for complex, multi-server environments.

    With advanced features like user-definable module data memory mapping up to 5000, 16-bit registers, this module ensures efficient data management. Its backward compatibility with previous versions and support for 10/100 Mbps auto crossover detection on Ethernet configuration and application ports make it adaptable to various network setups.

    The server capability of the MVI56-MNET module enables direct access from Human Machine Interfaces (HMIs), Supervisory Control and Data Acquisition (SCADA) systems, or Distributed Control Systems (DCS). It simplifies integration with these systems by providing access through the integrated RSLogix 5000 using an Add-On Instruction (AOI) or ladder file without requiring additional programming.

    This module also boasts faster response times for multi-server applications, which enhances operational efficiency and reduces delays. It minimizes the impact on other server communications when one server device experiences downtime, ensuring system reliability and stability.

    For network configuration and diagnostics monitoring, the CIPconnect-enabled feature allows the use of ControlLogix 1756-ENxT and 1756-CNB modules, enhancing troubleshooting capabilities. Additionally, the reduced I/O image size specifically optimizes remote rack implementations, making it suitable for various industrial settings.

    Prosoft’s MVI56-MNET module stands out with its robust design and advanced features, making it an indispensable component in modern industrial automation systems. It offers a blend of performance, reliability, and ease of integration, ensuring that your operations run smoothly and efficiently.
