Schneider EGX100MG Ethernet Gateway – Industrial Automation Module

Product Type:Ethernet Gateway

Model Number:EGX100MG

Rated Supply Voltage:24V DC

Power Dissipation:2.4W to 4W

Electrical Connection:1 Mini-DIN connector for terminal port (TER address), 1 RJ45 connector, 1 RJ45 connector for Uni-Telway auxiliary port, 1 SUB-D 9 connector for RS232 serial link (Modem)

Communication Protocol:Supports Ethernet (TCP/IP) and RS485

Data Transfer Rate:Up to 10 Mbps

    Introducing the Schneider EGX100MG Ethernet Gateway, the perfect solution for industrial environments requiring robust and reliable network connectivity. This advanced gateway effortlessly connects legacy industrial control systems with today’s Ethernet-based networks, enabling seamless communication and data exchange.

    Featuring a versatile array of communication protocols including EtherNet/IP, Profinet, and Modbus/TCP, this gateway ensures compatibility across diverse industrial systems. With a maximum data transfer rate of up to 10 Mbps, it guarantees fast and efficient data processing.

    Equipped with four Ethernet ports, the EGX100MG provides ample connectivity options for multiple devices. Its IP20 enclosure offers protection against dust and splashes, ensuring durability in harsh industrial settings.

    Designed for seamless integration, this gateway is compatible with Schneider Electric’s wide range of industrial automation products, enhancing system efficiency and reducing complexity in plant-wide networks.

    With an operating temperature range from -20°C to +55°C, the EGX100MG is built to withstand extreme environmental conditions, ensuring continuous operation in diverse industrial locations.

    The Schneider EGX100MG Ethernet Gateway is an indispensable addition to any industrial control system, offering high-speed networking capabilities and enhanced system integration, leading to improved operational efficiency and productivity.
