YASKAWA NPSO-0503L High-Precision Servo Control Module

Manufacturer:Yaskawa

Model Number:NPSO-0503L

Rated Voltage:AC 200V

Rated Current:3.2A

Rated Power:500W

Speed Range:100 to 3000 rpm

Resolution:17 bit

Inertia:0.00056 kg·m²

Weight:3.8 kg

Dimensions:160mm x 105mm x 225mm (LxWxH)

    The YASKAWA NPSO-0503L is a cutting-edge servo control module designed for industrial applications requiring high precision and reliability. Its advanced technology ensures smooth operation in demanding environments, making it ideal for use in robotics, CNC machinery, and other automated systems.

    This module features an Ethernet/IP and DeviceNet interface, allowing seamless integration with existing industrial networks. Additionally, it supports Profibus-DP and Modbus protocols, providing flexibility in system configuration and expansion.

    With a rated voltage range of 200-240VAC and a maximum current of 3.5A, the NPSO-0503L delivers reliable performance even under heavy load conditions. The frequency range of 0.1-400Hz ensures optimal control across a wide spectrum of applications.

    The module boasts a 13-bit resolution encoder, enabling precise positioning accuracy up to ±0.01mm. This level of accuracy is crucial for applications where minute adjustments can significantly impact overall system performance.

    Constructed with durable materials, the NPSO-0503L is designed to withstand harsh industrial environments. Its IP65 protection rating ensures it remains operational even in the presence of dust, moisture, and other contaminants.
